StarTech.com 4 Port Triple Monitor DVI USB KVM Switch with Audio & USB 2.0 Hub

StarTech.com 4 Port Triple Monitor DVI USB KVM Switch with Audio & USB 2.0 Hub

Name: StarTech.com 4 Port Triple Monitor DVI USB KVM Switch with Audio & USB 2.0 Hub
Brand: StarTech.com
SKU: SV431TDVIUA
Price: 593.98 EUR
Availability: OutOfStock

The SV431TDVIUA 4-Port Triple Monitor DVI USB KVM Switch allows 4 PCs (each with 3 DVI video outputs) to share monitors, 1 microphone and set of speakers, 1 keyboard and 1 mouse, as well as an additional USB 2.0 peripheral such as an external hard drive, thumb drive, printer, or webcam.

The Triple DVI KVM switch enables you to switch back and forth between 4 multi DVI PCs at the touch of a button, while maintaining professional-level video quality on all monitors at resolutions up to 1920x1200. The triple DVI KVM switch also features an integrated USB hub port which allows USB 2.0 peripherals to be shared between attached systems, eliminating duplicate peripheral costs and offering the convenience of sharing stored data between PCs.

The SV431TDVIUA 4-Port Triple Monitor DVI KVM Switch is backed by a StarTech.com 3-year warranty and free lifetime technical support.

PLEASE NOTE: While the DVI connector on this KVM is DVI-I, the KVM only supports single-link DVI-D (digital only) video sources. It is recommended wherever possible to use DVI-D cables across all PC to KVM and KVM to console connections.

Rackmount your KVM switch
If you’d like to mount this KVM switch to your server rack, StarTech.com offers a 1U Rackmount Bracket (sold separately) that turns this KVM into a rackmountable KVM.

The StarTech.com Advantage
- By enabling control of four triple display computer systems using a single set of peripherals, the switch helps saves cost and work space
- With support for high definition resolutions (1920x1200) on each of the 3 connected monitors, the triple head KVM switch offers maximum screen real estate for optimized productivity
- Integrated USB 2.0 hub and mic/audio ports enable you to have full multimedia control of two computers, while sharing USB peripherals

ON ORDER

SKU: SV431TDVIUA

Manufacturer: StarTech.com

RRP Price €593.98

Specifications

Ports & interfaces

Number of computers controlled

Keyboard port type

USB

Mouse port type

USB

Video port type

DVI-I

Console ports

3.5mm headphone, 3.5mm mic, USB A

Console USB ports quantity

Audio connections

Yes

Headphone outputs

Number of microphone inputs

DC-in jack

Yes

Performance

Maximum resolution

1920 x 1200 pixels

Maximum digital resolution

1920 x 1200 pixels

Scan interval

3,8,15,30 s

HDCP

Yes

Daisy chain

Number of users

1 user(s)

Design

Rack mounting

Yes

Product colour

Black

Housing material

Steel

LED indicators

Yes

Hot keys

Yes

Certification

CE, FCC, UL

Display

Built-in display

Power

Input voltage

110-240 V

Input current

0.8 A

Output voltage

12 V

Output current

1.5 A

External power adapter

Yes

Power plug type

Type M

Compatible power plug types

EU, UK, US

Sustainability

Compliance certificates

RoHS

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Storage temperature (T-T)

-10 - 60 °C

Operating relative humidity (H-H)

0 - 80%

Weight & dimensions

Width

219 mm

Depth

137 mm

Height

81 mm

Weight

1.5 kg

Packaging data

Package width

272 mm

Package depth

297 mm

Package height

108 mm

Package weight

2.2 kg

Packaging content

Manual

Yes

AC adapter included

Yes

Rubber feet

Yes

Other features

Audio support

Yes

IP control

Logistics data

Harmonized System (HS) code

85176200

Description

Manufacturer

StarTech.com

WH1 (1–2 Days)

N/A

WH2 (1–3 Days)

N/A

WH3 (5–7 Days)

N/A

Weight

1.496 kg

Country of Origin

N/A

Datasheet

Data Sheet

Download
