TP-Link TL-SF1008P network switch Unmanaged Fast Ethernet (10/100) Power over Ethernet (PoE) Olive

What This Product Does
TL-SF1008P is an 8 10/100Mbps ports unmanaged switch that requires no configuration and provides 4 PoE (Power over Ethernet) ports. It can automatically detect and supply power with all IEEE 802.3af compliant Powered Devices (PDs). In this situation, the electrical power is transmitted along with data in one single cable allowing you to expand your network to where there are no power lines or outlets, where you wish to ­fix devices such as APs, IP Cameras or IP Phones, etc.

Power over Ethernet
4 of the 8 Auto-Negotiation RJ45 ports (port-1 to port-4) of the switch support Power over Ethernet (PoE) function. These PoE ports can automatically detect and supply power with those IEEE 802.3af compliant Powered Devices (PDs).

-Overload Arrangement
TL-SF1008P has the priority function which will help protect the system when the system power is overloaded. If all PoE PDs power consumption is >= 57W, a priority will be arranged among the PoE ports, then the system will cut o‑ the power of the lowest-priority port.

-Port Priority Function
Priority (port-1=port-2=port-3>port-4): This function will help to ensure the normal operation of the system, it means Port 4 will be cut off when all total PoE PDs power consumption exceed 57W. For an example, Port 1, 2 and 4 is using 15.4W (maximum power for per port is 15.4W); the system power is 46.2W in total. If there is an additional PD inserted to Port 3 with 12W, and then the system will cut off the power of Port 4 because of the overloaded power, this means Port 1, 2 will use 15.4W, and Port3 will use 12W, no power will be supplied to Port 4.

Easy To Use

TL-SF1008P is easy to install and use. It requires no confi­guration and installation. With desktop design, outstanding performance and quality, the TP-LINK’s TL-SF1008P 8-Port 10/100Mbps Desktop Switch with 4-Port PoE is an ideal choice for expanding your home or office network.

ON ORDER

SKU: TL-SF1008P

Manufacturer: TP-Link TP-Link

RRP Price €0.00

Specifications

Management features

Switch type
Unmanaged

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity
8
Basic switching RJ-45 Ethernet ports type
Fast Ethernet (10/100)
Power connector
DC-in jack

Network

Networking standards
IEEE 802.1Qbb
10G support
No
Full duplex
Yes
Flow control support
Yes
Auto MDI/MDI-X
Yes
Ethernet LAN data rates
100 Mbit/s
MAC address auto-learning supported
Yes
MAC address auto-aging supported
Yes

Optical fiber

Fiber ethernet cabling technology
40GBASE-SR4

Data transmission

Switching capacity
1.6 Gbit/s
MAC address table
2000 entries
Store-and-forward
Yes

Security

DHCP features
DHCPv6 relay
Access Control List (ACL)
Yes

Protocols

GARP VLAN Registration Protocol (GVRP)
Yes
Routing protocols
OSPF
IPv4 & IPv6 features
IPv6 portal

Design

Rack mounting
No
Product colour
Olive
LED indicators
Yes
Number of fans
0 fan(s)

Performance

Expansion module support
Yes
Built-in processor
Yes
Processor manufacturer
Broadcom
Memory type
DRAM

Power

DC input voltage
48 V

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Yes
Power over Ethernet (PoE) ports quantity
4
Total Power over Ethernet (PoE) budget
60.2 W

Operational conditions

Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
10 - 90%
Storage relative humidity (H-H)
5 - 90%

Weight & dimensions

Width
171 mm
Depth
98 mm
Height
27 mm

Packaging content

User guide
Yes

Packaging data

Package type
Box

Certificates

Certification
FCC, CE, RoHS

Logistics data

Harmonized System (HS) code
85176990

Accessories

License
