Home > Switches > Teltonika > TSW101000000

Teltonika TSW101 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Metallic

AUTOMOTIVE POE+ SWITCHOur first-ever switch for the automotive industry features five Gigabit Ethernet ports with PoE+ support to connect multiple devices to the network and power them up using the same interfaces. Enjoy reliable high bandwidth connectivity in a simple, economical, and easy-to-install solution.

4 IN STOCK

RRP Price €60.65

  loading...
Register for Discounts

Specifications

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity
5
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Power connector
Terminal block (2-pin)

Network

Networking standards
IEEE 802.3, IEEE 802.3az, IEEE 802.3u
10G support
No
Auto MDI/MDI-X
Yes
Ethernet LAN data rates
10,100,1000 Mbit/s

Data transmission

Switching capacity
10 Gbit/s
MAC address table
2000 entries
Jumbo frames support
Yes
Jumbo frames
9216

Design

Product colour
Metallic
Housing material
Aluminium
LED indicators
Power, Status
International Protection (IP) code
IP30

Power

Power source
DC
Input voltage
9 - 30 V
Power consumption (typical)
0.64 W
Power consumption (max)
2.31 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Yes
Power over Ethernet (PoE) type supported
Passive PoE
Power over Ethernet (PoE) ports quantity
4
Power over Ethernet (PoE) power per port
30 W
Total Power over Ethernet (PoE) budget
120 W

Operational conditions

Operating temperature (T-T)
-40 - 75 °C
Operating relative humidity (H-H)
10 - 90%

Weight & dimensions

Width
115 mm
Depth
32 mm
Height
95 mm
Weight
354 g

Certificates

Certification
CE, REACH, RoHS, WEEE TSW101 CE TSW101 UKCA TSW101 FCC TSW101 IC TSW101 CB TSW101 RCM E-Mark

Logistics data

Harmonized System (HS) code
851762
Teltonika TSW101 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Metallic

Description

Manufacturer

Teltonika

WH1 (1–2 Days)

4

WH2 (1–3 Days)

N/A

WH3 (5–7 Days)

N/A

Weight

0.354 kg

Country of Origin

N/A

Datasheet

Data Sheet

Download
