Peplink Mobility 42G network antenna MIMO directional antenna SMA 8.2 dBi

Peplink Mobility 42G network antenna MIMO directional antenna SMA 8.2 dBi

Name: Peplink Mobility 42G network antenna MIMO directional antenna SMA 8.2 dBi
Brand: Peplink
SKU: ANT-MB-42G-S-W-16
Availability: InStock

4x Cellular | 1x GPS
With 4 cellular channels, the Mobility 40G is a powerhouse capable of delivering high bandwidth and solid reliability under heavy use. Equipped with high gain LNA, the GPS receiver has improved location tracking

23 IN STOCK

SKU: ANT-MB-42G-S-W-16

Manufacturer: Peplink Peplink

RRP Price €0.00

Specifications

Performance

Frequency band

0.617 - 6 GHz

Impedance

50 Ω

Antenna gain level (max)

8.2 dBi

LNA gain

28 dB

GPS frequency

1561 - 1602 MHz

Noise figure

1.5 dB

Features

Antenna type

MIMO directional antenna

Antenna connector type

SMA

Polarization

Linear polarization

International Protection (IP) code

IP68

Ultraviolet (UV) resistant

Yes

Survival wind speed

220 km/h

Power handling

10 W

Cable length

2 m

Cable type

CFD-200

Mounting

Wall/Pole

Power

Power consumption

8.5 mA

Input voltage

3.3 V

Certificates

Compliance certificates

REACH, RoHS, WEEE

Operational conditions

Operating temperature (T-T)

-40 - 80 °C

Storage temperature (T-T)

-40 - 80 °C

Weight & dimensions

Height

58 mm

Diameter

20.8 cm

Packaging data

Package width

231 mm

Package depth

216 mm

Package height

156 mm

Mobile network

4G standard

LTE

5G bands supported

600,700,800,850,900,1400,1500,1600,1700,1800,1900,2000,2100,2300,2400,2500,2600,2800,3500,5200 MHz

4G bands supported

700,800,900,1700,1800,1900,2000,2100,2500 MHz

Packaging content

Quantity per pack

1 pc(s)

Mounting kit

Yes

Mounting brackets included

Yes

Description

Manufacturer

Peplink

WH1 (1–2 Days)

N/A

WH2 (1–3 Days)

WH3 (5–7 Days)

N/A

Weight

N/A

Country of Origin

N/A

Datasheet

Data Sheet

Download
