Tripp Lite B070-016-19 NetCommander 16-Port Cat5 1U Rack-Mount Console KVM Switch with 19-in. LCD

This B070-016-19 KVM Switch gives you a rack-mountable full keyboard, LCD and touchpad in a single console that occupies only 1U of rack space. Easy to install and use, it’s the optimal solution for controlling up to 16 computers/servers.

The B070-016-19 uses inexpensive, user-supplied Cat5e/6/6a cabling and a Server Interface Unit so you can control computers/servers located up to 100 feet away from the switch. You can switch easily between the 16 ports using an on-screen display (OSD) or keyboard hotkey commands. Multi-level password protection prohibits unauthorized users from accessing the connected computers. The built-in 19-inch LCD screen supports video resolutions up to 1366 x 768.

The B070-016-19 stores neatly in a rack drawer and pulls out when needed. This KVM console is compatible with all major operating systems. Heavy-duty steel housing stands up to frequent use. Complies with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases.

Note: B051-000 remote access IP unit is not compatible with B070-008-19 or B070-016-19 NetCommander® Cat5 1U Rack-Mount Console KVM Switch Series.

ON ORDER

SKU: B070-016-19

Manufacturer: Eaton Eaton

RRP Price €1,551.65

Specifications

Display

Display diagonal
48.3 cm (19")
Display resolution
1280 x 1024 pixels
Display
LCD
On Screen Display (OSD)
Yes

Technical details

Height (in Rack Units)
1
Weight (imperial)
16.3 kg (36 lbs)
Product colour
Black
Built-in KVM switch
Yes
KVM switch ports quantity
16
Operating temperature (T-T)
-40 - 158 °F
Relative humidity
0 - 80%
Compliance certificates
RoHS
Country of origin
Taiwan

Ports & interfaces

I/O ports
16x RJ-45
Interface
VGA, USB, PS/2

Certificates

Certification
UL 60950-1 (USA), CAN/CSA (Canada), FCC Part 15 Class A, CE, IEC 60950-1

Power

AC adapter input voltage
100 - 240 V
AC adapter frequency
50/60 Hz

Weight & dimensions

Width
449.3 mm
Height
43.4 mm
Depth
722.4 mm
Weight
14 kg

Packaging data

Package weight
18.1 kg
Package width
594.4 mm
Package depth
830.1 mm
Package height
152.4 mm

Logistics data

Master (outer) case width
594.4 mm
Master (outer) case length
830.1 mm
Master (outer) case height
152.4 mm
Master (outer) case gross weight
18.1 kg
Products per master (outer) case
1 pc(s)
