Cisco C926-4P wired router Black

The Cisco 900 Series ISRs deliver integrated security and threat defense, protecting networks from both known and new Internet vulnerabilities and attacks. These powerful, fixed-configuration routers provide secure broadband and Metro Ethernet connectivity. Service providers offering managed Ethernet WAN services can deploy them in customer locations as CPE. Centralized and remote management capabilities are available through web-based tools and Cisco IOS® Software for full visibility and control of network configurations at the remote site.

The 900 Series ISRs simplify the deployment of Ethernet WAN services, with end-to-end Operations, Administration, and Maintenance (OA&M), Service-Level Agreement (SLA) monitoring and verification, and configuration management.

The Cisco 900 Series ISRs come with a 4-port managed switch, providing LAN ports to connect multiple devices. Figures 1 and 2 show the C921-4P and C926-4P models.

ON ORDER

SKU: C926-4P

Manufacturer: Cisco Cisco

RRP Price €485.00

Specifications

WAN connection

Ethernet WAN
Yes
SIM card slot
No
3G/4G USB modem compatibility
No

Network

Networking standards
IEEE 802.1x
Ethernet LAN
Yes
Ethernet LAN data rates
10,100,1000 Mbit/s
VLAN support
Yes
Multicast support
Yes
Auto MDI/MDI-X
Yes
Number of users
50 user(s)
Differentiated services (DiffServ) supported
Yes

DSL features

ADSL2+
Yes
VDSL2
Yes

Management features

Quality of Service (QoS) support
Yes

Ports & interfaces

Ethernet LAN (RJ-45) ports
4
USB ports quantity
1
USB version
2.0

Protocols

Routing protocols
BGP, EIGRP, OSPF
DHCP client
Yes
DHCP server
Yes

Security

Security algorithms
3DES, 128-bit AES, 192-bit AES, 256-bit AES, DES, SSL/TLS
Firewall
Yes
MAC address filtering
Yes
Access Control List (ACL)
Yes
Network address translation (NAT)
Yes

Features

Flash memory
2000 MB
Internal memory
1024 MB
Internal memory type
DRAM
Safety
IEC 60950-1, UL 60950-1, CAN/CSA C22.2 No. 60950-1, EN 60950-1, AS/NZS 60950.1

Design

Product colour
Black

Power

Power consumption (typical)
30 W
Power source type
AC
AC input voltage
100 - 240 V
AC input frequency
50 - 60 Hz
Output voltage
12 V

Operational conditions

Operating temperature (T-T)
0 - 45 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
5 - 95%
Storage relative humidity (H-H)
5 - 95%
Operating altitude
0 - 3000 m
Non-operating altitude
0 - 4570 m

Weight & dimensions

Width
259.1 mm
Depth
177.8 mm
Height
28 mm
Weight
1.2 kg

Logistics data

Harmonized System (HS) code
85176990

Accessories

License
