NETGEAR GSM4230P-100EUS network switch Managed L2/L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Black

NETGEAR GSM4230P-100EUS network switch Managed L2/L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Black

Name: NETGEAR GSM4230P-100EUS network switch Managed L2/L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Black
Brand: Netgear
SKU: GSM4230P-100EUS
Price: 1857.70 EUR
Availability: InStock

Pre-configured for out-of-the-box use
NETGEAR IGMP Plus™ enables instant multicast functionality for most AV over IP installations
Dedicated AV web-based GUI interface
Unique interface designed for the AV professional with color-coded, port-based profiles
Profiles for common audio protocols
Quickly assign profiles to ports for Dante, AES67, and AVB audio configurations. AVB Requires a separate license
Video profiles built-in
Special profiles for NVX, SVSI, Q-SYS and Dante video profiles can be easily assigned to ports as needed
Unique Automatic Configuration
Auto-trunk and auto-lag functionality automatically configures other M4250 switches for use in star topology.

Multi-switch audio or single-switch video deployments
24x1G PoE+ with 300W PoE budget with 2x1G additional ports and 4xSFP 1G fiber uplinks

Layer 2/Layer 3 Switching
Common Layer 2 and Layer 3 switching engine across all M4250 models

Control methods abound
Built-in IT web GUI, console, telnet and SSH consistent with other NETGEAR M4xxx series

Standard network features
Feature set includes static, RIP and PIM routing, DHCP Server and PTPv2

90 IN STOCK

SKU: GSM4230P-100EUS

Manufacturer: Netgear Netgear

RRP Price €1,857.70

Specifications

Management features

Switch type

Managed

Switch layer

L2/L3

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity

Basic switching RJ-45 Ethernet ports type

Gigabit Ethernet (10/100/1000)

SFP module slots quantity

Data transmission

Jumbo frames support

Yes

Jumbo frames

12000

Design

Rack mounting

Yes

Form factor

Product colour

Black

Performance

Noise level

34 dB

Fanless

Yes

Power

Power supply included

Yes

Power consumption (typical)

401 W

Power over Ethernet (PoE)

Yes

Power over Ethernet plus (PoE+) ports quantity

Power over Ethernet (PoE) power per port

30 W

Total Power over Ethernet (PoE) budget

300 W

Weight & dimensions

Width

440 mm

Depth

257 mm

Height

43.2 mm

Weight

4.3 kg

Packaging content

Cables included

AC, LAN (RJ-45), USB Type-C

User guide

Yes

Packaging data

Rack rails

Yes

Logistics data

Harmonized System (HS) code

85176990

Description

Manufacturer

Netgear

WH1 (1–2 Days)

N/A

WH2 (1–3 Days)

WH3 (5–7 Days)

Weight

4.3 kg

Country of Origin

N/A

Datasheet

Data Sheet

Download
