TP-Link Omada 28-Port Gigabit Smart Switch with 16-Port PoE+

- 24× Gigabit Ports (16× PoE+), 4× Gigabit SFP Slots
- 150 W Total PoE Budget
- Fanless Design for Silent Operation
- Zero-Touch Provisioning
- Centralized Management
- Omada App
- Static Routing
- Traffic Separation

Software Defined Networking (SDN) with Cloud Access
Remotely manage your access points, switches, and gateways across multiple sites all from a single interface.

Multiple Application Scenarios

Surveillance
Works with IP Cameras

Conference Call
Works with IP Phones

Wi-Fi Coverage
Works with Access Points

Wired Connections
Works with Non-PoE Devices such as PCs and Printers

20 IN STOCK

SKU: SG2428LP

Manufacturer: TP-Link TP-Link

RRP Price €323.05

Specifications

Management features

Switch type
Managed
Switch layer
L2/L2+
Quality of Service (QoS) support
Yes
Web-based management
Yes
Cloud-managed
Yes
ARP inspection
Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity
24
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
SFP module slots quantity
4

Network

Networking standards
IEEE 802.3af, IEEE 802.3at
10G support
No
Flow control support
Yes
Link aggregation
Yes
Spanning tree protocol
Yes
Auto-negotiation
Yes
VLAN support
Yes
Virtual LAN features
MAC address-based VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN
Number of VLANs
4000

Data transmission

Switching capacity
56 Gbit/s
Forwarding rate
41.66 Mpps
MAC address table
8000 entries
Jumbo frames support
Yes
Jumbo frames
9000
Packet buffer memory
4.1 MB

Security

DHCP features
DHCP relay, DHCP server
Access Control List (ACL)
Yes
IGMP snooping
Yes
MAC address filtering
Yes
Password protection
Yes

Multicast features

Multicast support
Yes

Design

Rack mounting
Yes
Product colour
Grey
LED indicators
Yes

Performance

Fanless
Yes

Power

Power source
AC/PoE
AC input voltage
100 - 240 V
AC input frequency
50/60 Hz
Power consumption (max)
184.7 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Yes
Power over Ethernet plus (PoE+) ports quantity
16
Power over Ethernet (PoE) power per port
30 W
Total Power over Ethernet (PoE) budget
150 W

Operational conditions

Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
10 - 90%
Storage relative humidity (H-H)
5 - 90%
Heat dissipation
628 BTU/h

Weight & dimensions

Width
440 mm
Depth
220 mm
Height
44 mm

Accessories

License
