Tripp Lite SR48UBEXPND SmartRack 48U Standard-Depth 4-Post Premium Open Frame Rack with No Sides or Doors

This SmartRack® 48U Standard-Depth 4-Post Premium Open Frame Rack has no doors and no side panels. The 'EXP' version is an expansion model used when several cabinets are bayed together. Its integrated baying tabs make it easy to combine multiple enclosures in rows for data center applications. This enclosure is also compatible with hot-aisle/cold-aisle configurations.

The SR48UBEXPND houses 3,500 pounds (1588 kilograms) of standard 19-inch rack equipment in 48U. Its front and rear pairs of vertical rails have square mounting holes that are adjustable in quarter-inch increments from four to 37 inches. Adjustment is quick and an easy-view depth index ensures consistent rail placement without requiring time-consuming measurements. Each rack space within the enclosure is numbered for ready reference.

Two of the adjustable vertical mounting rails support toolless button-mount 0U installation of up to four compatible PDUs and cable managers. This feature makes it easier to route cabling to rack equipment and reduces cord clutter.

All components of the SR48UBEXPND are grounded to the enclosure frame. Front and rear threaded grounding points are provided for connection to the facility earth ground.

To simplify deployment, the SR48UBEXPND comes with preinstalled casters that enable it to be easily maneuvered into the desired location, where it can be secured by adjusting the preinstalled levelers. Note: The casters are intended for minor position adjustments and are not designed for moving the enclosure over long distances.

ON ORDER

SKU: SR48UBEXPND

Manufacturer: Eaton Eaton

RRP Price €1,642.02

Specifications

Technical details

Product colour
Black
Depth (imperial)
6 m (236.3")
Height (imperial)
22.6 m (890")
Width (imperial)
6 m (236.3")
Country of origin
China

Certificates

Safety
EIA-310-E, IEC 60297-3-100, DIN 41494, RoHS, UL 60950

Other features

Dimensions (WxDxH)
6002 x 10920 x 22610 mm

Weight & dimensions

Weight
77.6 kg
Width
600.2 mm
Depth
1092.2 mm
Height
2260.6 mm

Packaging data

Package width
660.4 mm
Package depth
1143 mm
Package height
2413 mm
Package weight
96.6 kg

Logistics data

Master (outer) case width
660.4 mm
Master (outer) case length
1143 mm
Master (outer) case height
2413 mm
Master (outer) case gross weight
96.6 kg
Products per master (outer) case
1 pc(s)
Harmonized System (HS) code
8517.79.0000
