TP-Link TL-SG1210P network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey

PoE Switches for Your Ultra Convenience

10-Port Gigabit Desktop Switch with 8-Port PoE+
TL-SG1210P

Surveillance
Work with IP Cameras

Conference Call
Work with IP Phones

Wi-Fi Coverage
Work with Omada EAPs

Easy to Use

Power over Ethernet

Port 1-8 of the switch support Power over Ethernet (PoE) function. These PoE ports can automatically detect and supply power with those IEEE 802.3af/at compliant Powered Devices (PDs).

Intelligent Power Management

When total power consumption excels 63W, the intelligent power management will cut the lower priority port power off to ensure the high priority port’s power supply and protect the device from power overload operation.

Advanced Functions for Higher Performance

Qos
For Fluent Online Experience

Administrators can designate the priority of traffic based on QoS, for example, to ensure that voice and video applications remain clear and lag-free.

IGMP
Snooping
Traffic Optimization for IPTV

IGMP Snooping optimizes multimedia traffic delivery, to ensure a better network experience especially for applications like IPTV.

Sturdy Metal Casing

Sturdy, compact metal casing, with desktop/wall-mounting design, to meet your needs in any environment. Besides, fanless design ensures quiet operation.

24 IN STOCK

SKU: TL-SG1210P

Manufacturer: TP-Link TP-Link

RRP Price €80.89

Specifications

Management features

Switch type
Unmanaged
Quality of Service (QoS) support
Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity
9
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity
9
SFP module slots quantity
1

Network

Networking standards
IEEE 802.1p, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x
10G support
No
Copper ethernet cabling technology
10BASE-T, 100BASE-TX, 1000BASE-T
Auto MDI/MDI-X
Yes
Auto-negotiation
Yes
MAC address auto-learning supported
Yes
MAC address auto-aging supported
Yes

Optical fiber

Fiber ethernet cabling technology
1000BASE-X
Fiber type
Single-mode

Data transmission

Switching capacity
20 Gbit/s
MAC address table
4000 entries
Store-and-forward
Yes

Security

IGMP snooping
Yes

Design

Product colour
Grey
Housing material
Metal
LED indicators
Yes
Wall mountable
Yes

Performance

Fanless
Yes

Power

Power supply included
No
DC input voltage
53.5 V
Input current
1.31 A
Power consumption (typical)
7.11 W
Power consumption (max)
78.13 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Yes
Power over Ethernet plus (PoE+) ports quantity
8
Total Power over Ethernet (PoE) budget
63 W

Operational conditions

Operating temperature (T-T)
0 - 50 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
10 - 90%
Storage relative humidity (H-H)
5 - 90%
Heat dissipation
266.42 BTU/h

Weight & dimensions

Width
209 mm
Depth
126 mm
Height
26 mm

Packaging content

Cables included
AC
Quick start guide
Yes
User guide
Yes
Manual
Yes

Certificates

Certification
CE, FCC, RoHS

Logistics data

Harmonized System (HS) code
85176990
