Ubiquiti U7 Pro XGS 8600 Mbit/s Black Power over Ethernet (PoE)

Ubiquiti U7 Pro XGS 8600 Mbit/s Black Power over Ethernet (PoE)

Name: Ubiquiti U7 Pro XGS 8600 Mbit/s Black Power over Ethernet (PoE)
Brand: Ubiquiti
SKU: U7-PRO-XGS-B
Price: 330.89 EUR
Availability: InStock

Ceiling-mounted 8-stream WiFi 7 AP with dedicated spectral scanning radio and 10/5/2.5/1 GbE support.

91 IN STOCK

SKU: U7-PRO-XGS-B

Manufacturer: Ubiquiti

RRP Price €330.89

Specifications

Features

2.4 GHz

Yes

5 GHz

Yes

6 GHz

Yes

Maximum data transfer rate

8600 Mbit/s

Maximum data transfer rate (2.4 GHz)

688 Mbit/s

Maximum data transfer rate (5 GHz)

8600 Mbit/s

Maximum data transfer rate (6 GHz)

5800 Mbit/s

Ethernet LAN data rates

1000,2500,5000,10000 Mbit/s

Frequency band

2.4, 5, 6 GHz

Networking standards

IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11be, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v

Coverage area

160 m²

Number of users

500 user(s)

MIMO

Yes

MIMO type

Multi User MIMO

Spatial streams

Fit AP mode features

Hotspot 2.0

Fast roaming

Yes

VLAN support

Yes

Rate limiting

Yes

Wireless meshing

Yes

Band steering

Yes

Maximum Tx power (2.4 GHz)

23 dBmW

Maximum Tx power (5 GHz)

29 dBmW

Maximum Tx power (6 GHz)

24 dBmW

Security

Security algorithms

PPSK

Management features

Access point management

Wi-Fi schedule

Ports & interfaces

Ethernet LAN (RJ-45) ports

Power

Power over Ethernet (PoE)

Yes

Power over Ethernet (PoE) type supported

PoE++ (4PPoE)

Power consumption (max)

29 W

Design

Placement

Ceiling, Wall

Product colour

Black

Housing material

Metal, Polycarbonate (PC)

Reset button

Yes

LED indicators

Status

Antenna

Antenna type

Internal

Antenna gain level (max)

6 dBi

Certificates

Compliance certificates

CE, Federal Communications Commission (FCC), Industry Canada (IC)

Weight & dimensions

Width

215 mm

Depth

32.5 mm

Height

215 mm

Weight

800 g

Packaging content

Quantity per pack

1 pc(s)

Mounting kit

Yes

Operational conditions

Operating relative humidity (H-H)

5 - 95%

Operating temperature (T-T)

-30 - 40 °C

Description

Manufacturer

Ubiquiti

WH1 (1–2 Days)

N/A

WH2 (1–3 Days)

N/A

WH3 (5–7 Days)

Weight

0.8 kg

Country of Origin

N/A

Datasheet

Data Sheet

Download
