Ubiquiti U7 Pro XGS 8600 Mbit/s Black Power over Ethernet (PoE)

Ceiling-mounted 8-stream WiFi 7 AP with dedicated spectral scanning radio and 10/5/2.5/1 GbE support.

ON ORDER

SKU: U7-PRO-XGS-B

Manufacturer: Ubiquiti Ubiquiti

RRP Price €347.55

Specifications

Features

2.4 GHz
Yes
5 GHz
Yes
6 GHz
Yes
Maximum data transfer rate
8600 Mbit/s
Maximum data transfer rate (2.4 GHz)
688 Mbit/s
Maximum data transfer rate (5 GHz)
8600 Mbit/s
Maximum data transfer rate (6 GHz)
5800 Mbit/s
Ethernet LAN data rates
1000,2500,5000,10000 Mbit/s
Frequency band
2.4, 5, 6 GHz
Networking standards
IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11be, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v
Coverage area
160 m²
Number of users
500 user(s)
MIMO
Yes
MIMO type
Multi User MIMO
Spatial streams
8
Fit AP mode features
Hotspot 2.0
Fast roaming
Yes
VLAN support
Yes
Rate limiting
Yes
Wireless meshing
Yes
Band steering
Yes
Maximum Tx power (2.4 GHz)
23 dBmW
Maximum Tx power (5 GHz)
29 dBmW
Maximum Tx power (6 GHz)
24 dBmW

Security

Security algorithms
PPSK

Management features

Access point management
Wi-Fi schedule

Ports & interfaces

Ethernet LAN (RJ-45) ports
1

Power

Power over Ethernet (PoE)
Yes
Power over Ethernet (PoE) type supported
PoE++ (4PPoE)
Power consumption (max)
29 W

Design

Placement
Ceiling, Wall
Product colour
Black
Housing material
Metal, Polycarbonate (PC)
Reset button
Yes
LED indicators
Status

Antenna

Antenna type
Internal
Antenna gain level (max)
6 dBi

Certificates

Compliance certificates
CE, Federal Communications Commission (FCC), Industry Canada (IC)

Weight & dimensions

Width
215 mm
Depth
32.5 mm
Height
215 mm
Weight
800 g

Packaging content

Quantity per pack
1 pc(s)
Mounting kit
Yes

Operational conditions

Operating relative humidity (H-H)
5 - 95%
Operating temperature (T-T)
-30 - 40 °C

Accessories

License
