Zyxel XGS4600-52F Managed L3 Black

Stylish Outlook
New ID design with carbon fiber look name plate delivers the modern look-and-feel in the closet.
Choose a right L3 switch for your network

High Availability
The XGS4600 Series comes with Gigabit connectivity and four integrated 10-Gigabit SFP+ slots that enable high-speed uplink connections for affordable, reliable network elements.

Stacking Capability
The XGS4600-32/32F allows creating a physical stack through one or two 10-Gigabit SFP+ slots. XGS4600 series features dynamic routing to simplify cross-subnet communications for businesses such as hospitality venues and education institutions that operate complex networks.

High Resiliency
The XGS4600 Series is designed to support active-standby power redundancy to trigger backup power supply to take over in case the main power supply fails.

ON ORDER

SKU: XGS4600-52F-ZZ0101F

Manufacturer: Zyxel Zyxel

RRP Price €3,341.50

Specifications

Management features

Switch type
Managed
Switch layer
L3
Web-based management
Yes

Ports & interfaces

SFP module slots quantity
48
SFP+ module slots quantity
4

Network

Networking standards
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
10G support
Yes
IP routing
Yes

Data transmission

Switching capacity
176 Gbit/s
MAC address table
32000 entries
Packet buffer memory
4 MB

Security

DHCP features
DHCP server
Access Control List (ACL)
Yes
Security algorithms
SSH, SSL/TLS
MAC address filtering
Yes
SSH/SSL support
Yes
BPDU filtering/protection
Yes

Design

Rack mounting
Yes
Stackable
No
Product colour
Black
LED indicators
Yes

Performance

Internal memory
1024 MB
Flash memory
64 MB
Noise level
42.6 dB
Mean time between failures (MTBF)
815860 h

Power

AC input voltage
100 - 240 V
AC input frequency
50 - 60 Hz
Power consumption (max)
70.16 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)
No

Operational conditions

Operating temperature (T-T)
0 - 50 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
10 - 95%
Storage relative humidity (H-H)
10 - 95%
Heat dissipation
252.68 BTU/h

Weight & dimensions

Width
441 mm
Depth
360 mm
Height
44 mm
Weight
4.97 kg

Packaging data

Package width
616 mm
Package depth
355 mm
Package height
107 mm
Package weight
6.6 kg

Logistics data

Harmonized System (HS) code
85176990

Accessories

License
