Eaton 9PX 5000i HotSwap uninterruptible power supply (UPS) Double-conversion (Online) 5 kVA 4500 W 6 AC outlet(s)

Name: Eaton 9PX 5000i HotSwap uninterruptible power supply (UPS) Double-conversion (Online) 5 kVA 4500 W 6 AC outlet(s)
Brand: Eaton
SKU: 9PX5KIBP
Price: 4543.65 EUR
Availability: OutOfStock

The Eaton 9PX UPS provides energy-efficient power protection for small & medium Datacentres, IT rooms and Infrastructure. Delivering double conversion protection with 40% less energy usage and 28% more power 9PX is the perfect UPS for IT and Facility managers that are concerned by energy cost and are looking for next generation power protection solutions.

ON ORDER

SKU: 9PX5KIBP

Manufacturer: Eaton Eaton

RRP Price €4,543.65

Specifications

Features

UPS topology

Double-conversion (Online)

Output power capacity

5 kVA

Output power

4500 W

Waveform

Pure sine

Input operation voltage (min)

176 V

Input operation voltage (max)

276 V

Input frequency

40/70 Hz

Output operation voltage (min)

200 V

Output operation voltage (max)

240 V

Output frequency

50/60 Hz

Number of input phases

Efficiency

94%

Power factor

0.9

Output power factor

0.9

Crest factor

3:1

Output voltage Total Harmonic Distortion (THD)

Input current Total Harmonic Distortion (THD)

Noise level

45 dB

Ports & interfaces

AC outlet types

C13 coupler, C19 coupler, Terminal

Power plug

Terminal

AC outlets quantity

6 AC outlet(s)

USB port

Yes

USB 2.0 ports quantity

RS-232 ports

Battery

Battery technology

Sealed Lead Acid (VRLA)

Typical backup time at half load

13 min

Hot-swap battery

Yes

Automatic battery test

Yes

Design

Form factor

Rackmount/Tower

Rack capacity

Product colour

Black

Display type

LCD

LED indicators

Yes

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Certificates

Certification

IEC/EN 62040-1, UL 1778, IEC/EN 62040 -2, FCC Class A, IEC/EN 62040-3 (Performance), CE, CB report (TUV), UL

Safety regulation & standards

Safety

IEC/EN 62040-1, UL 1778

Sustainability

Sustainability certificates

ENERGY STAR

Weight & dimensions

Width

440 mm

Depth

685 mm

Height

130 mm

Weight

48 kg

Packaging data

Management card included

Bundled software

Intelligent Power Software suite

Logistics data

Harmonized System (HS) code

85078000

Other features

Nominal output voltage

230 V

Nominal input voltage

230 V

Description

Manufacturer

Eaton

WH1 (1–2 Days)

N/A

WH2 (1–3 Days)

N/A

WH3 (5–7 Days)

N/A

Weight

48 kg

Country of Origin

N/A

Datasheet

No Data Sheet Found!

Accessories

No Accessories Found!

License

No License Found!
