Digitus Bidirectional Gigabit Media Converter, RJ45 / SC

Digitus Bidirectional Gigabit Media Converter, RJ45 / SC

Name: Digitus Bidirectional Gigabit Media Converter, RJ45 / SC
Brand: Digitus
SKU: DN-82123
Price: 83.57 EUR
Availability: OutOfStock

The perfect converter solution for various fiber media

- Distance up to 20km
- Sends data in high quality and additionally provides excellent reliability
- A quick delivery is guaranteed in the gigabit range

The media converters from DIGITUS® are the ideal solution for the migration of copper and fiber network signals. From now on, you are able to access the fiber technology and transfer network signals over several kilometers without renewing your whole network infrastructure. The huge variety of products fulfil your individual needs. The intiutive operation guarantees a quick and easy installation.

ON ORDER

SKU: DN-82123

Manufacturer: Digitus Digitus

RRP Price €83.57

Specifications

Network

Maximum data transfer rate

1000 Mbit/s

Converter input interface

10Base-T, 100Base-TX, 1000Base-TX

Converter output interface

1000Base-LX

Networking standards

IEEE 802.3, IEEE 802.3u, IEEE 802.3z

Ethernet interface type

Gigabit Ethernet

Ethernet LAN data rates

10,100,1000 Mbit/s

Copper ethernet cabling technology

10BASE-T, 100BASE-TX, 1000BASE-TX

Fiber ethernet cabling technology

1000BASE‑LX

Data transfer rate

1000 Mbit/s

Auto MDI/MDI-X

Yes

Auto-negotiation

Yes

Duplex system

Full, Half

Link Loss Carry Forward (LLCF) supported

Yes

Link Loss Return (LLR) supported

Yes

Performance

Maximum transfer distance

20000 m

Wavelength

1550 nm

Wavelength-division multiplexing (WDM)

Yes

Fiber mode structure

Single-mode

Fiber cable diameters supported (core/cladding)

9/125 µm

Buffer size

2000 KB

Features

Internal

LED indicators

Link, Power, Status

Product colour

Black

Ports & interfaces

Connectivity technology

Wired

Ethernet LAN (RJ-45) ports

Fiber ports quantity

Fiber optic connector

DC-in jack

Yes

Power

Output voltage

5 V

Output current

0.8 A

Power consumption (typical)

2.5 W

Power over Ethernet (PoE)

External power adapter

Yes

Weight & dimensions

Width

70 mm

Depth

95 mm

Height

26 mm

Weight

200 g

Operational conditions

Operating temperature (T-T)

0 - 60 °C

Packaging content

AC adapter included

Yes

Quick installation guide

Yes

Packaging data

Package width

130 mm

Package depth

55 mm

Package volume

1716 cm³

Package weight

450 g

Package type

Box

Logistics data

Country of origin

China

UK Trade Tariff code

85176200

Harmonized System (HS) code

85176990

Description

Manufacturer

Digitus

WH1 (1–2 Days)

N/A

WH2 (1–3 Days)

N/A

WH3 (5–7 Days)

N/A

Weight

0.2 kg

Country of Origin

N/A

Datasheet

Data Sheet

Download
