Digitus 4K HDMI KVM Extender Set, 70 m

Name: Digitus 4K HDMI KVM Extender Set, 70 m
Brand: Digitus
SKU: DS-55513
Price: 227.75 EUR
Availability: InStock

Extends an HDMI signal over a distance of up to 70 m in UHD resolution (4K/60Hz) and offers KVM/USB functionality for the connection of mouse, keyboard and touchscreen

- Supports 4K2K/60Hz (HDR, 4:4:4)
- Video bandwidth: 18 Gbps
- Maximum transmission distance (UHD 4K2K): 70 m
- KVM/USB functionality – Connection of mouse, keyboard, touchscreen
- HDMI loop-out to the transmitter unit
- Supports CAT 6/7/8 cables
- Audio extractor on the receiver unit (S/PDIF)
- EDID passback
- HDCP 2.2 / 1.4
- HDMI 2.0
- USB 1.1

Extends an HDMI signal over a distance of up to 70 m in UHD resolution (4K/60Hz) and offers KVM/USB functionality for the connection of mouse, keyboard and touchscreen

1 IN STOCK

SKU: DS-55513

Manufacturer: Digitus Digitus

RRP Price €227.75

Specifications

Features

Type

Transmitter & receiver

Maximum transfer distance

70 m

Cable types supported

Cat6, Cat7, Cat8

Product colour

Black

Material

Aluminium

LED indicators

Status

Transmitter

Transmitter video port type

HDMI

Number of displays supported

RJ-45 ports quantity (transmitter)

Receiver

Receiver local video port type

HDMI

Receiver local keyboard/mouse port type

USB

RJ-45 ports quantity (receiver)

Ports & interfaces

USB port type

Mini-USB A

HDMI version

2.0

RJ-45 ports quantity

Power

AC adapter output voltage

5 V

AC adapter output current

2 A

Power consumption (transmitter) (max)

4 W

Power consumption (receiver) (max)

4 W

Weight & dimensions

Transmitter width

15 cm

Transmitter depth

10.7 cm

Transmitter height

2.8 cm

Transmitter weight

260 g

Receiver width

15 cm

Receiver depth

10.7 cm

Receiver height

2.8 cm

Receiver weight

260 g

Packaging data

Package width

153 mm

Package depth

357 mm

Package height

85 mm

Package weight

1.1 kg

Packaging content

AC adapter included

Yes

Cables included

USB

Manual

Yes

Mounting bracket(s) included

Yes

Operational conditions

Operating temperature (T-T)

-20 - 60 °C

Technical details

Maximum resolution

3840 x 2160 pixels

Package volume

4642.79 cm³

Logistics data

Country of origin

China

Description

Manufacturer

Digitus

WH1 (1–2 Days)

N/A

WH2 (1–3 Days)

WH3 (5–7 Days)

N/A

Weight

1.1 kg

Country of Origin

N/A

Datasheet

Data Sheet

Download
