Ubiquiti NanoStation 5AC Loco 1000 Mbit/s White Power over Ethernet (PoE)

The indoor/outdoor NanoStation® AC and NanoStation AC loco are compact, high-performance CPEs featuring airMAX® AC technology and a dedicated Wi-Fi radio for management.

Sleek Industrial Design
The NanoStation AC and NanoStation AC loco represent the next evolution of the iconic CPE design that revolutionized the Wireless ISP industry.

Dual Ethernet Connectivity
The NanoStation AC provides a secondary Ethernet port with software-enabled PoE. Use this port to conveniently power an external device, such as a PoE security camera, for seamless IP video integration.

Management Wi-Fi Radio
Each NanoStation AC model integrates a separate Wi-Fi radio for fast and easy setup using your mobile device.

Improved Surge Protection
The NanoStation AC and NanoStation AC loco feature enhanced protection against ESD events.

Now with airOS®8
airOS®8 provides powerful features, including airMAX® ac protocol support, real-time RF analytics, and an all-new design for enhanced usability.

133 IN STOCK

SKU: LOCO5AC

Manufacturer: Ubiquiti Ubiquiti

RRP Price €51.84

Specifications

Features

5 GHz
Yes
Maximum data transfer rate
1000 Mbit/s
Ethernet LAN data rates
10,100,1000 Mbit/s
Throughput data rate
450 Mbit/s
Frequency band
5.150 - 5.250, 5.250 - 5.350, 5.470 - 5.725, 5.725 - 5.850 GHz
Modulation
16-QAM, 64-QAM, 256-QAM, BPSK, QPSK
Maximum outdoor range
10000 m

Ports & interfaces

Ethernet LAN (RJ-45) ports
1

Power

Power over Ethernet (PoE)
Yes
AC input voltage
24 V
Input current
0.5 A

Design

Placement
Ceiling
Product colour
White
LED indicators
Network, Power, Signal strength

Antenna

Antenna type
Internal

Performance

Built-in processor
Yes
Internal memory
64 MB
Operating system installed
AirOS

Certificates

Certification
CE, FCC, IC

Weight & dimensions

Width
179 mm
Depth
77.5 mm
Height
59.1 mm
Weight
180 g

Operational conditions

Operating relative humidity (H-H)
5 - 95%
Operating temperature (T-T)
-40 - 70 °C

Logistics data

Harmonized System (HS) code
85176990
