Cisco Meraki MS210-48FP Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Grey

Cisco Meraki MS210 switches provide Layer 2 access switching for branch and small campus locations. The MS210 includes 4 x 1G SFP uplinks and physically stacks with the MS225 to gain access to its 10G uplink. This family also supports an optional, rack-mountable PSU (Cisco RPS-2300) for power redundancy requirements.

All Meraki switches are managed through an elegant, intuitive cloud-based interface, rather than cryptic command line.

To bring up a Meraki switch, simply plug it in. Meraki switches do not require CLI for switch configuration or port management.

Meraki’s centralized management platform gives administrators granular visibility into their network. Our dashboard helps you keep track of every configuration change in your network with our detailed event and change logs.

Hardware platform
- Reliable platform with 24/7 Meraki Support
- Clean lines and beautiful design
- Low noise, fanless model available
- Voice and video QoS
- Non-blocking switch fabric

Cloud management
- Email alerts for switch management
- Remote troubleshooting tools
- Manage ports from a GUI-based dashboard
- Zero-touch provisioning
- Per-port and per-client usage statistics
- Secure, user-scheduled firmware updates

Switching capabilities
- Layer 2 with Static Routes
- DHCP Relay
- 802.1X Authentication
- DHCP Snooping
- STP Enhancements
- IPv4 and IPv6 ACLs

ON ORDER

SKU: MS210-48FP-HW

Manufacturer: Cisco Cisco

RRP Price €4,458.62

Specifications

Management features

Switch type
Managed
Switch layer
L2
Quality of Service (QoS) support
Yes
Web-based management
Yes
System event log
Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity
48
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
SFP+ module slots quantity
4

Network

Networking standards
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1p, IEEE 802.1w, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at
10G support
No
Port mirroring
Yes
Flow control support
Yes
Link aggregation
Yes
Broadcast storm control
Yes
Spanning tree protocol
Yes
VLAN support
Yes
Number of VLANs
4094

Data transmission

Switching capacity
176 Gbit/s
Forwarding rate
127.98 Mpps
MAC address table
32000 entries
Number of queues
8
Jumbo frames support
Yes
Jumbo frames
9600

Security

DHCP features
DHCP relay
IGMP snooping
Yes
Security algorithms
802.1x RADIUS, SNMP
Loop protection
Yes
BPDU filtering/protection
Yes
Root protection
Yes

Protocols

Management protocols
IPv4, IPv6, SNMP
Routing protocols
CDP

Design

Rack mounting
Yes
Stackable
Yes
Form factor
1U
Product colour
Grey

Performance

Mean time between failures (MTBF)
320555 h

Power

AC input voltage
100 - 240 V
AC input frequency
47/63 Hz
Power consumption (max)
882 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Yes
Power over Ethernet (PoE) power per port
30 W
Total Power over Ethernet (PoE) budget
740 W

Operational conditions

Operating temperature (T-T)
-5 - 50 °C
Operating relative humidity (H-H)
5 - 95%

Weight & dimensions

Width
484.6 mm
Depth
340 mm
Height
43.8 mm
Weight
4.37 kg

Packaging data

Screws included
Yes

Certificates

Certification
CSA-US (US, Canada) FCC (USA) IC (Canada) CE (Europe) RCM (Australia/New Zealand) RoHS

Logistics data

Harmonized System (HS) code
85176990

Accessories

License
