Digitus Gigabit Active 802.3at PoE Midspan

Digitus Gigabit Active 802.3at PoE Midspan

Name: Digitus Gigabit Active 802.3at PoE Midspan
Brand: Digitus
SKU: DN-95132
Price: 25.78 EUR
Availability: InStock

The effective distance is 100 meters over Cat5e/Cat6 cables. It is small in size but high performance

- Provides 52Vdc, 0.58A power for remote PDs over 2 pairs output
- Supports both 10/100 Base-T and Gigabit device
- Works with a wide input voltage of 100-240 VAC, 50 or 60 Hz.
- Easily merge of power and data cables into a single cable
- Each output port has output current limited, short-circuit protection, complete Powered Device (PD) detection and classification
- The Injector can be used independent of operating system

DN-95132 is an indoor rated active PoE midspan Injector specially designed for complex backhaul and networking applications. It provides 52Vdc, 0.58A power for remote PDs over 2 pairs output. It supports both 10/100 Base-T and Gigabit device. It works for 30W PoE PDs, such as wireless APs, WLAN routers, Network cameras, IP Phones, Microwave Radio and other power Ethernet terminals. It fully complies to IEEE802.3af/at PoE standard. Enclosed in an IP40 fire retardant plastic case. Enclosed in an IP40 fire retardant plastic case. It works with a wide input voltage of 100-240 VAC, 50 or 60 Hz. It has detection chip inside, which will detect and classify PD before powering it. It will not provide power until a standard-compliant PD is detected.

2 IN STOCK

SKU: DN-95132

Manufacturer: Digitus Digitus

RRP Price €25.78

Specifications

Network

Ethernet interface type

Gigabit Ethernet

Ethernet LAN data rates

1000 Mbit/s

Power over Ethernet (PoE)

Yes

Networking standards

IEEE 802.3at

Features

Product colour

White

Housing material

Plastic

Plug and Play

Yes

LED indicators

Yes

Safety

CE/FCC

International Protection (IP) code

IP40

Ports & interfaces

Ethernet LAN (RJ-45) ports

Power

AC adapter input voltage

100 - 240 V

AC adapter frequency

50/60 Hz

Input current

1 A

Output current

0.58 A

Total Power over Ethernet (PoE) budget

30 W

DC output voltage

52 V

Certificates

Compliance certificates

RoHS, WEEE

Operational conditions

Operating temperature (T-T)

0 - 40 °C

Operating relative humidity (H-H)

20 - 80%

Storage temperature (T-T)

-20 - 70 °C

Operating altitude

0 - 2000 m

Weight & dimensions

Width

107.3 mm

Depth

56 mm

Height

34 mm

Weight

146.8 g

Packaging content

Number of products included

1 pc(s)

Manual

Yes

Packaging data

Package width

168 mm

Package depth

100 mm

Package height

43 mm

Package weight

36.25 g

Package volume

722.4 cm³

Logistics data

UK Trade Tariff code

85176200

Country of origin

China

Description

Manufacturer

Digitus

WH1 (1–2 Days)

N/A

WH2 (1–3 Days)

WH3 (5–7 Days)

Weight

0.1468 kg

Country of Origin

N/A

Datasheet

Data Sheet

Download
