Cisco Meraki MA-SFP-10GB-LR network transceiver module Fiber optic 10000 Mbit/s SFP+ 1310 nm

Name: Cisco Meraki MA-SFP-10GB-LR network transceiver module Fiber optic 10000 Mbit/s SFP+ 1310 nm
Brand: Cisco
SKU: MA-SFP-10GB-LR
Price: 6834.44 EUR
Availability: OutOfStock

SFP Transceivers are compliant with the Multi-Source Agreement (MSA) ensuring compatibility with a wide range of networking equipment. Select your choice or Copper or Fiber versions that support Fast Ethernet, Gigabit and 10G Ethernet speeds.

ON ORDER

SKU: MA-SFP-10GB-LR

Manufacturer: Cisco Cisco

RRP Price €6,834.44

Specifications

Performance

SFP transceiver type

Fiber optic

Maximum data transfer rate

10000 Mbit/s

Interface type

SFP+

Single-mode fiber (SMF) supported

Yes

Fiber optic connector

Fiber cable diameters supported (core/cladding)

9/125 µm

SFP transceiver standard

Wavelength

1310 nm

Networking standards

IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3u

Cabling technology

10GBASE-LR

Auto MDI/MDI-X

Yes

Features

Hot-Plug support

Yes

Certificates

Certification

MSA

Operational conditions

Operating temperature (T-T)

0 - 70 °C

Storage temperature (T-T)

-40 - 85 °C

Operating relative humidity (H-H)

10 - 80%

Storage relative humidity (H-H)

10 - 85%

Weight & dimensions

Width

13.4 mm

Depth

56.5 mm

Height

8.5 mm

Logistics data

Harmonized System (HS) code

85369010

Description

Manufacturer

Cisco

WH1 (1–2 Days)

N/A

WH2 (1–3 Days)

N/A

WH3 (5–7 Days)

N/A

Weight

N/A

Country of Origin

N/A

Datasheet

No Data Sheet Found!

Accessories

No Accessories Found!

License

No License Found!
