Trendnet TEG-10GECTX network card Internal Ethernet 10000 Mbit/s

TRENDnet’s 10 Gigabit PCIe Network Adapter, model TEG-10GECTX, converts a free PCI Express slot into a 10 Gigabit Ethernet port.

10 G Port

Supports five selectable speeds: 10 Gbps, 5 Gbps, 2.5 Gbps, 1 Gbps, and 100 Mbps

PCI Express

Converts a PCIe 2.0 x4 slot into a 10 G Ethernet Port

NBASE-Tâ„¢ Ethernet Technology

NBASE-T draft specification supports 2.5 and 5 Gbps speeds over standard Cat 5e cables at distances up to 100 m

Jumbo Frame

Sends larger packets, or jumbo frames (up to 16 KB), for increased performance

VLAN Support

IEEE 802.1Q tagged-based VLAN support

Brackets

Supports most installations with included standard and low-profile brackets

Operating Systems

Compatible with Windows®, Windows Server®, and Linux® operating systems.

LED Indicators

LED indicators convey port status, link speed and activity.

ON ORDER

SKU: TEG-10GECTX

Manufacturer: Trendnet Trendnet

RRP Price €80.43

Specifications

Ports & interfaces

Connectivity technology
Wired
Host interface
PCI Express
Interface
Ethernet
Ethernet LAN (RJ-45) ports
1

Network

Maximum data transfer rate
10000 Mbit/s
Networking standards
IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3an, IEEE 802.3u
Ethernet LAN
Yes
Ethernet interface type
10 Gigabit Ethernet
Ethernet LAN data rates
10,100,1000,10000 Mbit/s
Copper ethernet cabling technology
10BASE-T, 10GBASE-T, 100BASE-TX, 1000BASE-T
Jumbo frames support
Yes
Jumbo frames
16000
VLAN tagging
Yes

Design

Product colour
Green, Grey
Internal
Yes
LED indicators
Yes
Certification
FCC, CE

System requirements

Windows operating systems supported
Yes
Linux operating systems supported
Yes

Operational conditions

Operating temperature (T-T)
0 - 50 °C

Weight & dimensions

Width
84 mm
Depth
18 mm
Height
63 mm
Weight
62 g

Packaging data

Low-profile bracket
Yes

Packaging content

Mounting brackets included
Yes
Manual
Yes

Logistics data

Harmonized System (HS) code
85176990

Other features

Quick start guide
Yes
Receive Side Scaling (RSS)
Yes

Accessories

License
