Trendnet TI-RP262i Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U Black

TRENDnet's Industrial Gigabit L2 Managed PoE+ Rackmount Switch Series offers advanced layer 2 managed features with enhanced traffic controls to meet the evolving demands of today's SMB networks. Each industrial layer 2 rackmount switch is equipped with an IP30 rated metal enclosure, designed to withstand a high degree of vibration and shock, while operating within a wide temperature range of -40° – 70° C (-40° – 158° F) for industrial environments. Our industrial layer 2 rackmount switch models feature copper gigabit ports for high-speed device connections, as well as SFP slots that support 100/1000Base-FX SFP modules for long distance fiber networking applications. These industrial layer 2 rackmount switches feature a fanless design that eliminates operating noise and lowers energy consumption.

These Industrial Gigabit L2 Managed PoE+ Rackmount Switch Series provides an intuitive web-based management interface. Each TRENDnet industrial layer 2 rackmount switch supports advanced traffic management controls, troubleshooting, and SNMP monitoring. Advanced managed switch features include LACP to group ports together and increase bandwidth between switches, VLANs for segmenting and isolating virtual LAN groups, QoS to prioritize traffic, port bandwidth controls, SNMP monitoring, and more, making each TRENDnet industrial layer 2 rackmount switch a powerful solution for SMB networks.

L2 Management
Provides an easy to use web management interface for traffic management controls such as VLAN, QoS, access controls, link aggregation, troubleshooting, SNMP monitoring, and per port MAC restriction.

PoE Power
A 685W PoE power budget supplies up to 24 Power over Ethernet devices, and includes advanced PoE port controls, such as enabling / disabling PoE, power priority, PD alive check, and power scheduling.

Industrial Design
Equipped with an IP30 rated metal enclosure, designed to withstand a high degree of vibration and shock, while operating within a wide temperature range of -40° – 70° C (-40° – 158° F) for industrial environments.

Network Ports
24 x Gigabit PoE+ ports and 2 x SFP slots allow for a 52Gbps switching capacity, and 1 x console port (RJ-45 to RS-232) for out-of-band management

PoE Power
Industrial layer 2 PoE+ rackmount switch supplies up to 30W of PoE+ power per port with a 685W total PoE power budget

Full PoE Control Per Port
Available PoE port controls on the industrial layer 2 PoE+ rackmount switch include enabling / disabling PoE, power priority, PD alive check, and power scheduling

Traffic Management
Managed features include 802.1Q, IGMP v1 / 2 / 3, IGMP Snooping, per port bandwidth control / 802.1p / DSCP / Queue Scheduling (SPQ / WRR), STP / RSTP, static and dynamic link aggregation, and ERPS for flexible network integration

Layer 2 Management
Offers IPv4 / IPv6 static or DHCPv4 / v6 assignment, DHCP server / relay / option 82, and DHCP server snooping / screening to filter out unauthorized DHCP servers

Access Control
Managed access control features include ACLs, IP-MAC-Port binding, ARP inspection, 802.1X RADIUS, MAC address learning, DHCP snooping, and IP Source Guard provides layered network access controls

System Monitoring
Monitoring features include SNMP v1 / v2c / 3, MIB support, SNMP trap, RMON Groups (1, 2, 3, 9), SMTP alert, syslog, port mirroring, and ModBus / TCP

19” Rackmount
Sturdy rack mountable metal housing with mounting kit included

Fanless Design
Industrial layer 2 rackmount switch with a fanless design to eliminate operating noise and lower energy consumption

Switching Capacity
52Gbps switching capacity

Redundant Power
Multiple power inputs are featured on the industrial layer 2 rackmount switch with overload current protection (power supply sold separately: TI-RSP100048)

Jumbo Frame
Sends larger packets, or Jumbo Frames (up to 10KB), for increased performance

Wide Temperature Range
A wide operating temperature range of -40° – 70° C (-40° – 158° F) allows the industrial layer 2 rackmount switch to be installed in extreme hot or cold environments

Shock and Vibration Resistant
Rated for shock (EN 60068-2-27), freefall (EN 60068-2-32), and vibration (EN 60068-2-6)

Grounding Point
Grounding point on the industrial layer 2 rackmount switch protects equipment from external electrical surges

ON ORDER

SKU: TI-RP262I

Manufacturer: Trendnet Trendnet

RRP Price €1,153.13

Specifications

Management features

Switch type
Managed
Switch layer
L2
Quality of Service (QoS) support
Yes
Web-based management
Yes
ARP inspection
Yes
System event log
Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity
24
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
SFP module slots quantity
2
Console port
RJ-45

Network

Networking standards
IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
10G support
No
Port mirroring
Yes
Link aggregation
Yes
Broadcast storm control
Yes
Spanning tree protocol
Yes
MAC address auto-learning supported
Yes
VLAN support
Yes
Virtual LAN features
MAC address-based VLAN, Tagged VLAN
Number of VLANs
4094

Data transmission

Switching capacity
52 Gbit/s
Forwarding rate
38.7 Mpps
MAC address table
8000 entries
Store-and-forward
Yes
Jumbo frames support
Yes
Jumbo frames
10000
Packet buffer memory
0.5 MB

Security

DHCP features
DHCP Option 82, DHCP relay, DHCP server, DHCP snooping
Access Control List (ACL)
Yes
IGMP snooping
Yes
Security algorithms
SNMP, SNMPv2, SNMPv3, SSH-2
BPDU filtering/protection
Yes
Queue scheduling algorithms
SP, WFQ, Weighted Round Robin (WRR)

Multicast features

Multicast support
Yes
Number of multicast groups filtered
256

Design

Rack mounting
Yes
Form factor
1U
Product colour
Black
Housing material
Metal
LED indicators
Yes
International Protection (IP) code
IP30

Performance

Fanless
Yes
Mean time between failures (MTBF)
475352 h

Power

Power consumption (max)
705 W
Power protection features
Over current, Short circuit

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Yes
Power over Ethernet plus (PoE+) ports quantity
24
Power over Ethernet (PoE) voltage
48 V
Power over Ethernet (PoE) power per port
30 W
Total Power over Ethernet (PoE) budget
685 W

Operational conditions

Operating temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
0 - 95%

Weight & dimensions

Width
440 mm
Depth
310 mm
Height
44 mm
Weight
3.58 kg

Packaging content

Quick start guide
Yes
Rack mount kit
Yes

Certificates

Certification
CE FCC IEC 60068-2-27 IEC 60068-2-32 IEC 60068-2-6

Logistics data

Harmonized System (HS) code
85176990
