Trendnet TI-PG541i Managed L2+ Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black

TRENDnet’s 6-Port Hardened Industrial Gigabit PoE+ Layer 2 Managed DIN-Rail Switch, model TI-PG541i, has four Gigabit PoE+ ports, one Gigabit port, one Gigabit SFP slot and a 120 Watts PoE budget. The switch is equipped with an IP30 rated metal enclosure and designed to withstand a high degree of vibration, shock, protection against ESD/EMI/surge, and operate within a wide temperature range (- 40 – 70 °C (- 40 - 158 °F)) for harsh environments. L2 management include features such as PoE port control, VLAN, multicast, and QoS which allow for network integration flexibility.

Industrial Hardened Design
Equipped with a rugged IP30 rated enclosure and designed to withstand a high degree of vibration, shock, protection against ESD/EMI/surge, and operate with a wide temperature range (- 40 – 70 °C (- 40 - 158 °F)) for harsh environments.

Integration Flexibility
Managed features include PoE per port control/priority/scheduling/power delay, 802.1Q/MAC-based VLAN, IGMP snooping, per port bandwidth control/802.1p/DSCP/queue scheduling, and SNMP trap/RMON/SMTP alert/syslog/port mirror for monitoring and flexible network integration.

Fault Tolerance
Features dual redundant power inputs (Primary and RPS) from external power sources and an output alarm relay to indicate the event of input power failure

Full PoE+ Power Budget
Supplies up to 30 Watts of PoE/PoE+ power per port (ports 1-4 802.3at/802.3af) with a 120 Watt PoE power budget

Network Ports and Capacity
4 x Gigabit PoE+ ports, 1 x Gigabit Port, and 1 x Gigabit SFP slot allow for a 12Gbps switching capacity

Integrated DIN-Rail Mount
IP30 rated metal enclosure with integrated DIN-rail mounting hardware

Full PoE Control Per Port
PoE control features include enabling/disabling PoE and class, power priority, PD alive check, scheduling, and power delay per port using CLI or web management.

L2 Management
Managed features include 802.1Q, /MAC-Based VLAN, IGMP v1/2/3 Snooping, per port bandwidth control/802.1p/DSCP/Queue Scheduling (SP/WFQ/WRR), and Storm Control for flexible network integration.

System Monitoring
Monitoring features include SNMPv1/v2c, MIB support, SNMP trap, RMON Groups (1, 2, 3, 9), SMTP alert, syslog, and port mirroring.

Redundant Power
Dual redundant power inputs (primary and RPS) with overload current protection

Alarm Output
Alarm relay output triggered by power failure of primary and/or redundant power (DIP switch)

Jumbo Frame
Sends larger packets, or Jumbo Frames (up to 10K)

Wide Temperature
Hardened switch is rated for an operating temperature range of - 40 to 70 °C (-40 to 158 °F)

Electro Magnetic Compliance
Complies with IEC61000-6-2 EMC generic standard immunity for industrial environments

Shock and Vibration Resistant
Rated for shock (IEC 60068-2-27), freefall (IEC 60068-2-32), and vibration (IEC 60068-2-6)

LED Indicators
LED indicators convey power, redundant power, alarm, SFP, PoE, and network port status

Grounding Point
Grounding point protects equipment from external electrical surges

ON ORDER

SKU: TI-PG541I

Manufacturer: Trendnet Trendnet

RRP Price €284.83

Specifications

Management features

Switch type
Managed
Switch layer
L2+
Quality of Service (QoS) support
Yes
Web-based management
Yes
ARP inspection
Yes
System event log
Yes
MIB support
RFC 1213, RFC 1493, RFC 1643, RFC 1757

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity
5
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
SFP module slots quantity
1

Network

Networking standards
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
10G support
No
Port mirroring
Yes
Full duplex
Yes
Link aggregation
Yes
Broadcast storm control
Yes
MAC address auto-learning supported
Yes
VLAN support
Yes
Virtual LAN features
Tagged VLAN, Protocol-based VLAN
Number of VLANs
256

Data transmission

Switching capacity
12 Gbit/s
Throughput
8.93 Mpps
MAC address table
16000 entries
Jumbo frames support
Yes
Jumbo frames
10000
Packet buffer memory
128 MB

Security

DHCP features
DHCP server
Access Control List (ACL)
Yes
IGMP snooping
Yes
Security algorithms
802.1x RADIUS, HTTPS, SNMP
Loop protection
Yes
Authentication
Port-based authentication

Multicast features

Multicast support
Yes
Multicast MAC address table
256 entries

Design

Rack mounting
No
Product colour
Black
LED indicators
Yes
International Protection (IP) code
IP30
DIN rail mounting
Yes

Performance

Mean time between failures (MTBF)
435905 h

Power

Redundant power supply (RPS) support
Yes
AC input voltage
100 - 240 V
AC input frequency
50 - 60 Hz
Output voltage
48 V
Output current
5 A
Power consumption (max)
130 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)
Yes
Power over Ethernet plus (PoE+) ports quantity
4
Power over Ethernet (PoE) power per port
30 W
Total Power over Ethernet (PoE) budget
120 W

Other features

Terminal block port
Yes

Operational conditions

Operating temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
0 - 95%

Weight & dimensions

Width
135 mm
Depth
120 mm
Height
31 mm
Weight
528 g

Packaging content

Quick start guide
Yes

Packaging data

Terminal block included
Yes
Package type
Box
Resource CD
Yes

Logistics data

Harmonized System (HS) code
85176990
